1、精餾塔：工業萘精餾塔一般采用浮閥塔，浮閥板層50—70層，塔徑按處理量的大小有800—1200mm。

1. Distillation tower: Industrial naphthalene distillation tower generally uses a float valve tower, with 50-70 layers of float valve plates, and a tower diameter of 800-1200mm according to the processing capacity.

2、冷凝冷卻器：冷凝冷卻器是一個直徑為1.2m，長為3.376m，冷卻面積為122m2的列管式換熱器，生產時冷卻水走管內，萘蒸汽以138-140℃的溫度從器頂進入管間，換熱后再以80—90℃的溫度從器底呈液體流出。冷卻水從器底進入，器上部以40—50℃溫度流出

2. Condensing cooler: A condensing cooler is a tubular heat exchanger with a diameter of 1.2m, a length of 3.376m, and a cooling area of 122m2. During production, the cooling water flows through the pipes, and naphthalene vapor enters the pipes at a temperature of 138-140 ℃ from the top of the condenser. After heat exchange, it flows out as a liquid at a temperature of 80-90 ℃ from the bottom of the condenser. Cooling water enters from the bottom of the device and flows out from the top at a temperature of 40-50 ℃

3、轉鼓結晶機：其結構如圖1-8所示圖1-8 轉鼓結晶機轉鼓結晶機是將熔融狀態的萘連續冷卻成固態散裝萘的機器。轉鼓結晶機由機殼、保溫池、轉鼓、刮刀、冷卻水管和傳動裝置組成。

3. Drum crystallizer: Its structure is shown in Figures 1-8. Drum crystallizer is a machine that continuously cools molten naphthalene into solid bulk naphthalene. The drum crystallizer consists of a casing, insulation pool, drum, scraper, cooling water pipe, and transmission device.

4、工業萘汽化冷凝冷卻器：汽化冷凝冷卻器由上、下兩部分組成。

4. Industrial naphthalene vaporization condenser: The vaporization condenser consists of two parts: upper and lower.
