吸收萘的方法很多，一般采用焦油洗油吸收，洗油的性質如下表所示。吸收萘的方法大致有下列三種，下面精萘廠家為您分析：

There are many methods for absorbing naphthalene, usually using tar wash oil for absorption. The properties of the wash oil are shown in the table below. There are roughly three methods for absorbing naphthalene, and the refined naphthalene manufacturer will analyze for you below:

洗油的性質

Properties of washing oil

（一）吸收法

（1） Absorption method

用洗油吸收煤氣中的萘，再將富萘油蒸餾，除萘后的洗油循環使用。根據富萘油的蒸餾方式可以分為以下三種：

Absorb naphthalene from gas with washing oil, then distill the naphthalene rich oil, and recycle the washing oil after removing naphthalene. According to the distillation methods of naphthalene rich oil, it can be divided into the following three types:

（1）側線切出法。

(1) Side cut method.

將富萘油與洗苯富油同時在一個蒸餾塔內蒸餾，從塔的側線切出萘餾分。這種方法建設投資低，但是萘餾分中含萘量低，洗油損耗大。

Distill the naphthalene rich oil and benzene washing rich oil simultaneously in a distillation tower, and cut the naphthalene fraction from the side line of the tower. This method has low construction investment, but the naphthalene content in the naphthalene fraction is low and the washing oil loss is large.

（2）兩段蒸餾法。

(2) Two stage distillation method.

采用兩個蒸餾塔蒸餾，從第一塔的塔頂取出萘-苯餾分，塔底取出洗油。這種方法操作簡單，切出的萘餾分含萘高。

Two distillation towers are used for distillation, with naphthalene benzene fraction taken out from the top of the first tower and wash oil taken out from the bottom of the tower. This method is simple to operate and the cut naphthalene fraction contains high naphthalene.

（3）單獨蒸餾法洗。

(3) Wash by separate distillation method.

萘富油不與洗苯富油混合，而采用單獨蒸餾的方法。蒸餾采用（2）項的兩段蒸餾法。這種方法建設費用高、占地面積大。但這個方法的大優點是腐蝕成分集中在萘蒸餾部分，這樣可降低苯蒸餾部分的材質標準。

Naphthalene rich oil is not mixed with benzene washing rich oil, but is distilled separately. Distillation adopts the two-stage distillation method in item (2). This method has high construction costs and a large floor area. But the major advantage of this method is that the corrosive components are concentrated in the naphthalene distillation section, which can reduce the material standard of the benzene distillation section.

（二）冷卻法

（2） Cooling method

在冷卻煤氣的同時使萘析出，并與冷卻水一同流出，往冷卻水中混入焦油，吸收水中的萘，然后靜置分離出冷卻水。水在涼水架冷卻后循環使用。

While cooling the gas, naphthalene is precipitated and flows out together with the cooling water. Tar is mixed into the cooling water to absorb the naphthalene in the water, and then the cooling water is separated by standing still. The water is recycled after being cooled in a cooling rack.

這個方法的大優點是不要蒸餾裝置，建設費用約為前述方法的一半，并且不必?fù)?dān)心因腐蝕而中斷操作。在處理萘比較麻煩的冬季，因水溫低；煤氣冷卻的幅度可增大，所以效率也提高。能夠大大改進維護檢修。但是，采用型式的涼水架冷卻循環水時，會污染環境，如果是換熱器，則擔心堵塞管子，尤其作為動力，每小時需消耗幾噸蒸汽，所以操作費增高些。

The major advantage of this method is that it does not require distillation units, the construction cost is about half of the previous method, and there is no need to worry about interrupting operations due to corrosion. In the winter when dealing with naphthalene is quite troublesome, due to the low water temperature; The cooling range of gas can be increased, so the efficiency also improves. It can greatly improve maintenance and repair. However, when using a type of cooling water rack to cool the circulating water, it will pollute the environment. If it is a heat exchanger, there is a concern about clogging the pipes, especially as power, which requires several tons of steam per hour, so the operating cost will increase.

（三）直接油冷方法

（3） Direct oil cooling method

此方法是b冷卻法的進一步發展，采用焦油或重油代替冷卻水直接噴灑煤氣并吸收萘，吸收了萘的焦油、重油作為燃料油使用是沒有問題的，但該法除萘效率比前述兩種方法都低。

This method is a further development of the B cooling method, which uses tar or heavy oil instead of cooling water to directly spray gas and absorb naphthalene. The tar and heavy oil that absorb naphthalene can be used as fuel oil without any problems, but the naphthalene removal efficiency of this method is lower than that of the previous two methods.
